50mA Output Closed Loop Current Sensor , Hall Current Transducer Blue Color

Name: 50mA Output Closed Loop Current Sensor Hall Current Transducer Blue Color
Brand: chieful
Price: 1 USD

Wholesale 50mA Output Closed Loop Current Sensor , Hall Current Transducer Blue Color from china suppliers

Brand Name : chieful

Model Number : CSM150LA

Certification : CE,Rohs,ISO9001

Place of Origin : China

MOQ : 1pc

Price : Negotiable

Payment Terms : T/T

Supply Ability : 10000pcs/month

Delivery Time : 7 working days

Packaging Details : carton

color : blue

weight : 19g

window size : 12.5*7mm

Capacity : 10000pcs/month

Accuracy : 0.7%

Warranty : 5years

Contact Now

50mA output , window size 12.5*7mm Closed Loop Current Transducer

Features:

Closed loop current sensor based on the principle of Hall-effect. It can be used for
measuring AC,DC,pulsed and mixed current.

Closed loop Hall effect current transducer are for the real-time precision measurement of currents: DC, AC, pulse and irregular wave currents with galvanic isolation between the primary circuit and the secondary circuit.

Electrical characteristics
	Type	CSM150LA
I_PN	Primary nominal input current	150	A
I_P	Measuring range of primary current	0~±150	A
I_SN	Secondary nominal output current	75	mA
K_N	Conversion ratio	1:2000
R_M	Measuring resistance	V_C=±15V I_P=±150A 0-33	Ω
V_C	Supply voltage	±15(±5%)	V
I_C	Current consumption	V_C=±15V 10+Is	mA
V_D	Insulation voltage	AC/50Hz/1min 2.5	kV
ε_L	Linearity	<0.2	%FS
X	Accuracy	T_A=25℃ V_C=±15V <±0.7	%
I_O	Zero offset current	T_A=25℃ <±0.2	mA
I_OM	Residual current	I_P→0 <±0.15	mA
I_OT	Thermal drift of I₀	I_P=0 T_A=-25~+85℃ <±0.5	mA
T_R	Response time	<1	μs
f	Frequency bandwidth(-1dB)	DC~100	kHz
T_A	Ambient operating temperature	-25~+85	℃
T_S	Ambient storage temperature	-40~+100	℃
R_S	Secondary coil resistance(T_A=25℃)	112	Ω
m	Mass	19	g
	Standard	Q/320115QHKJ01-2016
